MC2 : Downlight Directed Illuminated Module (Louvered) 120V/277V Direct

Downlight Directed Illuminated Module (Louvered) 120V/277V Direct

Compatible Items
Similar Items

Downloads

Description

2000lm (12")
3000lm (18")

Benefits

Multiple beam spread options
Glare free illumination
Minimal 1" square

Available Features ?

Available Features

Based on the option chosen these features will be available. Please check the webpage and specification sheet to ensure the particular feature applies to your product.

Order Configurator

Length *

MC212: 12", 2000lm (22W)
MC218: 18", 3000lm (33W)

You can not select this item

Finish *

B: Black
W: White

You can not select this item

Driver *

Blank: 120V Phase Dimming
UE-D10: 120V 0-10V Dimming
UE-DUN: UniDim 0-10V ELV and Triac Dimming

You can not select this item

Beam Spread *

-B15: 15° Narrow Spot
-B30: 30° Flood
-B40: 40° Wide Flood

You can not select this item

CCT *

-T27: 2700K, 90 CRI
-T30: 3000K, 90 CRI
-T35: 3500K, 90 CRI
-T40: 4000K, 90 CRI

You can not select this item

* Required Fields

Availability: In stock

Dimming Diagrams
